Single Color White

Auragami Single Color White is the award-winning flexible LED light sheet with leading performance and energy-efficiency. Available in 5 standard color temperatures with a color rendering index up to 95+. Our light sheet is optimized for Class 2. This allows for connecting up to 8 light sheets (10ft²) while eliminating extraneous power supply costs.

2700K

3000K

3500K

4000K

5300K

Custom

SpecificationS

Electrical

Input Voltage

24 Volt DC – Constant Voltage

Power Consumption

11W per sheet (8.65w/ft², 93.1W/m²), 0.03W per LED

Wires

20AWG 2-conductor (grey striped wire +, white wire –)

Power Connection

Twelve integrated 2-pin connection blocks

Certification

IP65, cULus Listed (E495221), CE Compliant (EMC and LVD), and RoHS Certified

Physical

Color Temperature

2700K, 3000K, 3500K, 4000K, 5300K, Custom

Color Rendering Index

92+ for 2700K, 95+ for 3000K, 3500K, 4000K, 5300K

Light Output

1100 lumens per sheet

Mounting

Insert screws through circles marked on sheet. High-bonding 3M adhesive backing is a supplementary method.

Environment

IP65 Rated for Wet locations

Dimensions

19.8" x 9.25 (503.5mm x 235mm)

Cut Increments

Short axis: 0.66" (16.8mm) / long axis: 0.66" (16.8mm)

LED Density

420 LEDs per sheet, 332 LEDs per ft² (3,572 LEDs per m²)

LED Type

2835 SMD

Product Weight

5 oz (141g) per sheet

Features

Field Customizable

Maintains UL Listing when cut

Power Grid

Single LEDs or LED groups may be removed from any part of the light sheet

PCB Construction

Flexible / foldable, polyimide film substrate

Quality Control

Tight ANSI bin control LEDs

Energy Efficiency

100 lumens per watt

Rated Life

50,000 + hours

Warranty

5-year advanced warranty / Learn more

Integration Support

Dedicated integration support from concept to completion

Power & Controls

Compatible with full range (100%-0%), flicker-free power, and control components. Quality tested for low-end light output consistency across all LEDs. Please contact Evo-Lite for optimal solutions to fit your requirements.

Product Wiring & Control Advisory

1. The light sheet's integrated connection blocks have a 4A capacity. Do not exceed the load capacity of these connection blocks in any configuration.

2. To retain Class 2 compliance per UL regulation use one 96W 24VDC Class 2, LPS, or LVLE power supply / channel to interconnect up to 8 light sheets (88W). Best practice includes allowing headroom for power supply longevity.

See Spec Sheet for more information

Auragami small 5V single color white sample

seeing is believing.
Request an Auragami sample.

See what makes Auragami extraordinary with a portable sample. Auragami samples are available in single color white, tunable white, and RGBW. Choose from convenient portable battery powered samples or full-size sheet samples to test your forward-facing materials!

Request a Sample

Frequently Bought together

Check out these great accessories for the Auragami product line.

View all Auragami Accessories
TRAX centipede cable

Power Input Kit - SCW

Power up to 8 light sheets with the single color power input kit.

TRAX centipede cable

Sheet Connector Pack – SCW

Additional single color sheet connectors in short or long lengths.

TRAX centipede cable

Auragami Bumpers

Light sheet bumpers that support the forward-facing material.

TRAX centipede cable

Installation Roller

Auragami roller helps apply light sheets to surfaces.

Ordering

View specification sheet to learn more.

Auragami Single Color White Flexible Light Sheets

AG1-24-27

2700K. Includes light sheet and accessory pack (2 short sheet-to-sheet connectors, 2 long sheet-to-sheet connectors, 8 bumpers).

AG1-24-30

3000K. Includes light sheet and accessory pack (2 short sheet-to-sheet connectors, 2 long sheet-to-sheet connectors, 8 bumpers).

AG1-24-35

3500K. Includes light sheet and accessory pack (2 short sheet-to-sheet connectors, 2 long sheet-to-sheet connectors, 8 bumpers).

AG1-24-40

4000K. Includes light sheet and accessory pack (2 short sheet-to-sheet connectors, 2 long sheet-to-sheet connectors, 8 bumpers).

AG1-24-53

5000K. Includes light sheet and accessory pack (2 short sheet-to-sheet connectors, 2 long sheet-to-sheet connectors, 8 bumpers).
