Lumisheet Product Line

LumiSheetTM offers advanced light distribution in a low-profile, energy-efficient package.

LumiSheet single color white edgelit light panel LED waveguide

Single Color White

Edgelit Light Panels are available in several standard single-color white temperatures including 2700K, 3000K, 3500K, 4100K, 5300K, 6500K.

LumiSheet Edgelit Light Panel Waveguide tunable white 2700-6500K

Tunable White

Why settle for one static color when Tunable White light panels offer a full range of relaxing 2700K warm white to energizing 6500K bright white.

LumiSheet by Evo-Lite RGB RGBW edgelit light panel LED waveguide


RGB & RGBW light panels offer deeply vibrant colors and are great tools for creating color sequence effects using DMX or any other modern controls.

The Features that make it great

See why lighting professionals all over the world choose LumiSheetTM Light Panels.

Fusion Waveguide consistent light output

Consistent light output

LumiSheetTM provides even illumination across the entire surface of the light panel.

Fusion Waveguide accurate color rendering

Accurate color rendering

Enjoy deep and true-to-life colors with an industry-leading color rendering index of 95+.

Auragami Flexible Light Sheet in single color white, tunable white, and rgbw

Versatile illumination

LumiSheetTM is great for backlighting stone, graphics, and any other semi-transparent material.

Auragami with solder free plug in play connectors

Optimized to order

LumiSheetTM is individually crafted for each project. This means they are optimized for your exact need.

Auragami folded

Great at any scale

LumiSheetTM performs at any scale - from small residential projects to massive architectural features.

Custom Auragami Solution

Low-profile builds

LumiSheetTM can backlight many materials with no spatial diffusion necessary. This allows for sleek, elegant builds.



Input Voltage

24 Volt DC – Constant Voltage, 12VDC optional

Power Consumption

4.4W/ft (single color), 2.4W/ft (single color low wattage), 8W/ft (tunable white), 4.4W/ft (RGB), 4.9W/ft (RGBW)


20AWG (single color), 22AWG (tunable white, RGB, RGBW)

Power Connection

Barrel plug-in connector or stripped wire ends


cULus Listed (E346146)


Color Temperature

2700K, 3000K, 3500K, 4000K, 5300K,
2700-6500K Tunable White, RGB, RGBW

Color Rendering Index


Light Output

Dependent on panel size and shape


Surface mount


IP22 dry locations


2" x 2" (50 x 50mm) minimum,
59" x 118" (1500 x 3000mm) maximum

Product Weight

~1.95 lbs/ft2 (~9.54 kg/m2) (8mm LGP)



Dimmable, offering consistent low-level output

Custom Wire Exits

Configure wire exit where most convenient

Illumination Options

LEDs on 1 side, 2 sides, or 4 sides

Mounting Options

Pre-drilled holes, z-clips, or edge clips / standoffs

Long Lifespan

70,000 hour rated life


3-year advanced warranty / Learn more

Power & Controls

Compatible with full range (100%-0%), flicker-free power, and control components. Quality tested for low-end light output consistency across all LEDs. Please contact Evo-Lite for optimal solutions to fit your requirements.

Class 2 & UL Compliance

Use Class 2 power supplies with a maximum power output of 96W (per channel/circuit) to retain UL Class 2 Listing compliance. Best practices include allowing headroom for power supply longevity.
